APC-12-700 12W 700mA 9...18VDC Konstantstrom LED Netzteil Treiber Trafo
Produktnummer:
IT-005796
- Breite: 40mm
- Leistung: 12W
- Eingangsspannung (min...max): 90...264VAC
- Konstantstrom: 700mA
- Topologie: AC/DC Wandler
Produktinformationen "APC-12-700 12W 700mA 9...18VDC Konstantstrom LED Netzteil Treiber Trafo"
| ✔ KonstantStrom Netzteil |
| ✔ Universaleingang |
| ✔ Kunststoffgehäuse IP30 |
| ✔ Überlastschutz durch Strombegrenzung |
| ✔ geschützt gegen Kurzschluss, Überlast, Überspannung |
| ✔ für LED- und Beleuchtungsanwendungen |
Technische Daten
| Anschluss Ausgang: | Kabel: 2x15cm |
|---|---|
| Anschluss Eingang: | Kabel: 2x15cm |
| Ausgangsspannung (min…max): | 9...18VDC |
| Breite: | 40mm |
| Eingangsspannung: | 115V / 230V (Universal) |
| Eingangsspannung (min...max): | 90...264VAC |
| Höhe: | 29mm |
| Konstantstrom: | 700mA |
| Leistung: | 12W |
| Länge: | 77mm |
| Netzteil Typ: | LED Netzteil |
| Stabilisierung: | Konstantstrom |
| Topologie: | AC/DC Wandler |
| Wirkungsgrad: | 80% |
